Date 02.10.2026 - 12:10:24
MC-Filename multiple-screenshots.mcam
Postprocessor MPFAN.PST
Material ALUMINUM mm - 2024
Stock X200.00 Y160.00 Z120.00
Programmer Alf
User name GMCCS
Computer name LAPTOP-A3A0R4IM
Machine MILL DEFAULT MM.MCAM-MMD
Machine group Machine Group-1
CSS Documentation
JavaScript Documentation
Comment

This template is designed to transform a standard CNC setup sheet into a consolidated, sorted Tool Table. It identifies unique tools, aggregates their total cycle times, determines their maximum physical depth (z-Min), and provides an interactive UI for sorting and image inspection.

Tl # Tl BMP Operation type Comment Cutter comp Tl type Tl diam. Tl corner rad Tl length Tl Cutlength Stock XY Stock Z Z-Min Cycle time
4 Facing Bullnose 32.0 5.0 30.0 25.0 0.0 0.0 0.0 1:16:44
1 3D High Speed (Dynamic OptiRough) Bullnose 12.0 0.5 70.0 25.0 0.35 0.35 -69.65 0:19:50
Stock model Nach dem Schruppen 0.0 0.0 0:00:00
2 3D High Speed (Dynamic OptiRest) Bullnose 6.0 0.5 40.0 16.0 0.35 0.35 -69.65 0:04:49
Stock model Nach dem Restmaterial 0.0 0.0 0:00:00
3 3D High Speed (Dynamic OptiRest) Ball endmill 5.0 2.5 50.0 25.0 0.35 0.35 -45.032 0:36:50
5 3D High Speed (Waterline) Ball endmill 8.0 4.0 50.0 25.0 0.0 0.0 -69.722 3:49:22
5 3D High Speed (Raster) Ball endmill 8.0 4.0 50.0 25.0 0.0 0.0 -70.0 7:16:30
3 3D High Speed (Blend) Ball endmill 5.0 2.5 50.0 25.0 0.0 0.0 -43.995 0:46:19
14:10:25
