| Date | 10.02.2026 - 09:52:06 |
| MC-Filename | multiple-screenshots.mcam |
| Postprocessor | TNC530i_NEW.pst |
| Material | ALUMINUM mm - 2024 |
| Stock | X200.00 Y160.00 Z120.00 |
| Programmer | Alf |
| User name | GMCCS |
| Machine | TNC530i_new.mcam-mmd |
| Key features |
|
Enter some text!
| Tl # | Tl BMP | Holder (new) | Operation type | Comment | Cutter comp | Tl type | Tl diam. | Tl corner rad | Tl length | Tl Cutlength | Stock XY | Stock Z | Z-Min | Cycle time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 |  |
B2C4-1000 | Planen | Radienfräser | 32.0 | 5.0 | 30.0 | 25.0 | 0.0 | 0.0 | 0.0 | 1:16:44 | ||
| 1 |  |
B3E4-0750 | 3D HSC (3D Dynamisches Schruppen) | Radienfräser | 12.0 | 0.5 | 70.0 | 25.0 | 0.35 | 0.35 | -69.65 | 0:19:51 | ||
| Rohteil | Nach dem Schruppen | 0.0 | 0.0 | 0:00:00 | ||||||||||
| 2 |  |
B2E4-0250 | 3D HSC (Dynamisches OptiRest) | Radienfräser | 6.0 | 0.5 | 40.0 | 16.0 | 0.35 | 0.35 | -69.65 | 0:04:50 | ||
| Rohteil | Nach dem Restmaterial | 0.0 | 0.0 | 0:00:00 | ||||||||||
| 3 |  |
B2C3-0016 | 3D HSC (Dynamisches OptiRest) | Kugelfräser | 5.0 | 2.5 | 50.0 | 25.0 | 0.35 | 0.35 | -45.032 | 0:36:51 | ||
| 5 |  |
B2E4-0562 | 3D HSC (Z-Konstant) | Kugelfräser | 8.0 | 4.0 | 50.0 | 25.0 | 0.0 | 0.0 | -69.722 | 3:49:24 | ||
| 5 | |
B2E4-0562 | 3D HSC (Parallel) | Kugelfräser | 8.0 | 4.0 | 50.0 | 25.0 | 0.0 | 0.0 | -70.0 | 7:16:54 | ||
| 3 | |
B2C3-0016 | 3D HSC (Blenden) | Kugelfräser | 5.0 | 2.5 | 50.0 | 25.0 | 0.0 | 0.0 | -43.995 | 0:46:21 | ||
| 14:10:55 | ||||||||||||||
| Tl # | Tl BMP | Holder (new) | Operation type | Comment | Cutter comp | Tl type | Tl diam. | Tl corner rad | Tl length | Tl Cutlength | Stock XY | Stock Z | Z-Min | Cycle time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | |
B3E4-0750 | 3D HSC (3D Dynamisches Schruppen) | Radienfräser | 12.0 | 0.5 | 70.0 | 25.0 | 0.35 | 0.35 | -69.65 | 00:19:51 | ||
| 2 | |
B2E4-0250 | 3D HSC (Dynamisches OptiRest) | Radienfräser | 6.0 | 0.5 | 40.0 | 16.0 | 0.35 | 0.35 | -69.65 | 00:04:50 | ||
| 3 | |
B2C3-0016 | 3D HSC (Dynamisches OptiRest) | Kugelfräser | 5.0 | 2.5 | 50.0 | 25.0 | 0.35 | 0.35 | -45.032 | 01:23:12 | ||
| 4 | |
B2C4-1000 | Planen | Radienfräser | 32.0 | 5.0 | 30.0 | 25.0 | 0.0 | 0.0 | 0.0 | 01:16:44 | ||
| 5 | |
B2E4-0562 | 3D HSC (Parallel) | Kugelfräser | 8.0 | 4.0 | 50.0 | 25.0 | 0.0 | 0.0 | -70.0 | 11:06:18 | ||
| 14:10:55 | ||||||||||||||
